| Stock # | 102700 |
| Year | 2026 |
| Make | Grand Design |
| Model | Reflection |
| Trim | 324MBS |
| Condition | NEW |
| Status | AVAILABLE |
| BUILD SHEET - CLICK HERE | |
| General | |
|---|---|
| Category Class | Fifth Wheel |
| Secondary Class | Bunkhouse, Rear Livingroom, Two Bedroom |
| VIN | 573FR3826T9930601 |
| Overall Size | |
|---|---|
| Exterior Height | 12' 3" |
| Exterior Height (w/opt. AC) | 12' 9" |
| Exterior Length (FT/IN) | 37'' |
| Exterior Width (IN/MM) | 8 ft. (96 in.) |
| Weights | |
|---|---|
| UVW (lbs) | 10864 LBS |
| Gross Weight Rating (LB/KG) | 13,995 lbs. LBS |
| Capacity | |
|---|---|
| Max Sleeping Count | 6 |
| Total Fresh Water Tank Capacity (GAL/L) | 74 |
| Total Gray Water Tank Capacity (GAL/L) | 87 |
| Total Black Water Tank Capacity (GAL/L) | 47 |
| Number of LP Tanks | 2 |
| LP Tank Capacity | 60 |
| Appliances | |
|---|---|
| Water Heater Tank | Yes |
| Refrigerator Power Mode | Electric |
| Number Of Stove Burners | 3 |
| Heater BTU | 35,000 BTUs |
| Heater Type | Automatic |
| AC BTU | 15,000 BTU |
| Electrical Service | 50AMP |
| Running Gear | |
|---|---|
| Number Of Axles | 2 |
| Construction | |
|---|---|
| Construction Type | Aluminum Cage |
| Floor R-Value | R-30 |
| Wall R-Value | R-9 |
| Roof R-Value | R-40 |
| Slide Room R-Value | R-9 |
| Dimensions | |
|---|---|
| Number Of Bunks | 2 |
| Number Of Couches | 0 |
| Number Of Convertible Sofa Beds | 1 |
| Number Of Bathrooms | 1 |
| Shower Size | Center |
| Dinette Type | U-shaped Dinette |
| Exterior | |
|---|---|
| Number Of Slideouts | 3 |
| Awning Length | 19 ft. (228 in.) |
| Number Of Doors | 1 |
| Grill/Griddle | YES |
| TV | Yes |
| Exterior Fridge | YES |
| Leveling Jack Type | AUTO-LEVELING JACKS |
| Other Specifications | |
|---|---|
| Wheels Composition | Aluminum |
| Front Brake Type | Not Applicable |
| Rear Brake Type | Electric Drum |
| Length (FT) | 37' 0" |
| Number Of Propane Tanks | 2 |
| Total Propane Tank Capacity (GAL/LBS) | 60 lbs. |
| Body Material | Fiberglass |
| Power Retractable Awning | Yes |
| Kitchen Location | Center |
| Living Area Location | Rear |
| Overhead Fan | Yes |
| Layout | Oven / Stove |
| Number Of Double Beds | 0 |
| Number Of Full Size Beds | 0 |
| Number Of Queen Size Beds | 1 |
| Number Of King Size Beds | 0 |
| Bunkhouse | Yes |
| Bathroom Flooring Type | Vinyl |
| Bathroom Location | Center |
| Air Conditioning Prewiring | Yes |
| Cable Prewiring | Yes |
| Phone Prewiring | No |
| Heat Prewiring | Yes |
| Satellite Prewiring | Yes |
| Washer/Dryer Prewiring | Yes |
| Number Of Emergency Exits | 1 |
| Air Conditioning Type | Automatic |
| Water Heater Pump Power Mode | Electrical |
| Water Heater Tank Bypass | Yes |
| Surround Sound | Yes |
| Rear Video Backup Camera | Yes |
| Solar Battery Charger | Yes |
| Toilet | Center |
| Air Conditioning | 15,000 BTUs |
